Spatial Audio & Immersive Music for Liquid Drum and Bass: Atmospheric Drum and Bass, Soulful Drum and Bass & Jazzstep
Spatial9 Team · · 9 min read
Part of the series Spatial audio and immersive music by genre.
Key takeaways
- In a spatial liquid drum and bass mix the kick, snare and warm sub bass stay locked in the centre, while the vocal, Rhodes keys, ghost percussion, strings, hats, pads and vocal echoes spread around the listener.
- Splitting the soulful vocal and the Rhodes chords to different sides keeps lyrics clear, because sounds from different directions mask each other less, an effect known as spatial release from masking.
- Liquid drum and bass gains most from width and space, so strings, pads and reverb should wrap the listener while the fast drums stay fairly dry and centred.
- The liquid drum and bass immersion profile scores width 5, height 4, movement 3, low-end focus 4 and space 5 out of 5.
Liquid drum and bass is the soulful, melodic side of drum and bass. It took shape in the UK in the late 1990s and early 2000s, first under the name liquid funk, building on the atmospheric drum and bass of the mid 1990s. It keeps the drum and bass tempo, usually around 170 to 176 BPM, but swaps aggressive bass design for warm sub bass, jazz and soul chords, Rhodes and piano, strings, pads and sung vocals. The drums still roll fast, yet the mood is relaxed and emotional. Because the track runs at two speeds, quick drums over slow, lush harmony, there is a lot of space to fill around the beat. That space is where spatial audio does its best work. This guide covers how spatial audio for liquid drum and bass works, where to place each element and how to make an immersive liquid drum and bass mix. For the basics, see what spatial audio is.
Why liquid drum and bass is ideal for spatial audio
Liquid drum and bass is full of long, warm sounds: held string chords, soft pads, Rhodes voicings and reverb tails. In stereo they pile up behind the drums and the vocal, and the mix can turn muddy. In an immersive mix the harmony can surround the listener while the drums and sub stay tight in the middle, so the track feels both fast and calm.
The rule: tight drums in the middle, warm harmony all around. The kick, snare and sub stay put, while keys, strings and pads build a room around the listener.
Immersive music for liquid drum and bass: what listeners hear
- Drums that roll without rushing. Kick and snare stay tight and centred.
- A voice close to you. The vocal sits just off centre, warm and clear.
- Harmony that surrounds you. Strings, keys and pads fill the sides and the space above.
- Echoes that drift away. Vocal delays float slowly behind the listener.
Where to place each element in a liquid drum and bass mix
| Element | Position | Height | Why it works |
|---|---|---|---|
| Kick & snare | Front centre | Ear level | The fast, steady roll |
| Sub bass | Centre | Ear level | Warm, round low end |
| Lead vocal | Front left | Ear level | Soulful and close |
| Ghost perc | Front right, moving | Ear level | Light swing between the hits |
| Rhodes keys | Left | Ear level | Jazz and soul chords beside the groove |
| Strings | Right | Raised | Lift and emotion above the drums |
| Rolling hats | Behind right | Raised | Shimmer that keeps the pace |
| Pads | Behind left | Raised | A warm bed around the listener |
| Vocal echo | Behind, moving | Raised | Delays that drift and fade |
The psychoacoustics behind liquid drum and bass placement
Every position in the table above follows how the ear and brain locate sound. Here is the reason behind the main choices for liquid drum and bass.
- Sub bass stays centred. The ear finds almost no direction in frequencies below roughly 80 to 100 Hz, so a liquid sub gains nothing from being spread. Keeping it centred and mono keeps it round and steady on any system, from a club to earbuds.
- Vocal and Rhodes on separate sides. Two sounds that share a frequency range mask each other far less when they arrive from different directions. This is spatial release from masking. Soul vocals and Rhodes chords both sit in the mids, so splitting them keeps every word clear.
- Strings and hats raised. The outer ear shapes the spectrum of a sound differently depending on its height, and the brain reads those spectral cues as elevation (Hebrank and Wright). Bright strings and hats carry the high frequencies these cues rely on, so they lift convincingly above the drums.
- Pads around and behind. Sound arriving from the sides soon after the direct sound is what makes a room feel wide and enveloping. Spreading liquid pads and reverb around the listener creates the warm, open feeling the genre is known for.
The immersion profile for liquid drum and bass
Width and space are at maximum because strings, keys, pads and reverb are central to the sound. Height is high because strings and hats sit naturally above the drums. Movement is only moderate: the drums are fast, but the feel is smooth, so only light percussion and echoes travel. Low-end focus is strong but below heavier drum and bass styles, because the sub is warm and supportive rather than the main event.
Tips for an immersive liquid drum and bass mix
- Keep the sub mono. The warm bass must stay identical from every direction.
- Keep the drums tight. Fast breaks smear in a big room, so keep the main hits fairly dry and centred.
- Give the harmony the space. Let strings, keys and pads wrap the listener rather than the drums.
- Keep the vocal close. A soulful vocal should feel intimate, with its echoes doing the travelling.
- Move slowly. Use gentle, gradual motion so the track stays calm at full tempo.
Liquid Drum and Bass styles: atmospheric drum and bass, soulful drum and bass and jazzstep
The core placement holds for every liquid style: drums and sub in the middle, harmony around the listener. What changes is how much space the track needs and which instruments carry the melody.
Atmospheric Drum and Bass
Atmospheric drum and bass, sometimes called intelligent drum and bass, came first, in the mid 1990s, and it is the most spacious of the three. Long pads, ambient textures and washed-out samples matter more than vocals. Push pads and textures wide and high so they surround the listener, and let field recordings or ambient samples sit far behind. Keep the breaks light and centred, with rides raised. Use long reverb on the atmosphere but keep the drums fairly dry so they do not blur.
Soulful Drum and Bass
Soulful drum and bass is built around a sung vocal, often with gospel or soul phrasing, plus piano, strings and warm chords. The vocal is the focus, so keep it front and close, slightly off centre, with backing vocals spread wider on both sides and slightly raised. Piano and Rhodes can sit left, strings right and high. Let vocal delays drift behind. Keep the sub warm and centred so the emotion of the song stays on top.
Jazzstep
Jazzstep emerged in the late 1990s and blends drum and bass rhythms with jazz harmony and instruments: double bass, horns, vibraphone, piano and live-sounding drums. Place it like a small band around the listener. Horns and vibes can take the front sides, piano a little further left, and the double bass stays centred with the sub. Keep the drum kit fairly natural in front, with cymbals raised. A shorter room reverb suits the live feel better than long pads.
Related styles such as minimal liquid and sambass follow the same idea: tight drums and sub in the middle, with melody and harmony spread around the listener.
How to make immersive liquid drum and bass from stereo
Spatial9 can create spatial audio from a stereo track in a few steps:
- Upload your stereo master or your stems.
- Spatial9's AI separates and places each part, keeping the drums and sub tight in the centre and wrapping vocals, keys, strings and pads around you.
- Preview it in binaural on headphones.
- Export Eclipsa Audio, ADM, binaural or Ambisonics.
- Publish a video. Create a YouTube-ready video with your immersive audio and publish it directly.
For related guides, read spatial audio for drum and bass and spatial audio for jungle. Every guide is listed in spatial audio and immersive music by genre.
Frequently asked questions
Does this guide cover atmospheric drum and bass, soulful drum and bass and jazzstep?
Yes. Atmospheric drum and bass pushes pads and textures wide and high around light breaks. Soulful drum and bass keeps the sung vocal front and close with keys and strings around it. Jazzstep places horns, vibes, piano and double bass like a small band around the listener.
Can I make a liquid drum and bass mix in Dolby Atmos or Eclipsa Audio?
Yes. The placements in this guide work for both. Spatial9 exports ADM, the standard file used by Dolby Atmos studios, as well as Eclipsa Audio for YouTube, so one immersive liquid drum and bass mix covers both. If you plan to release the Atmos version on Apple Music, build it from your original stems or multitracks, because Apple does not accept Atmos made from a finished stereo master. See where to publish spatial audio. You may also hear this called a 3D liquid drum and bass mix or liquid drum and bass in spatial audio.
Is spatial audio good for liquid drum and bass?
Yes. Liquid drum and bass is full of long, warm sounds that crowd a stereo mix. Spatial audio wraps them around the listener while the drums and sub stay tight.
How is liquid drum and bass different from drum and bass in spatial audio?
Liquid drum and bass needs more width and space for strings, keys and pads, and less movement. Heavier drum and bass styles focus on aggressive bass design and fast movement, with the sub and the bass at the centre of the mix.
Where should the vocal go in immersive liquid drum and bass?
Front and close, just off centre. Keep the main vocal fairly dry and let its echoes and harmonies drift around and behind the listener.
Can I convert a finished liquid drum and bass track to spatial audio?
Yes. Spatial9 uses AI to generate an immersive mix from a stereo master and exports it as Eclipsa Audio, ADM, binaural or Ambisonics.
Does immersive liquid drum and bass work on normal headphones?
Yes. The mix is rendered binaurally, so the rolling drums and warm, wide harmony work on any regular headphones.
Dolby and Dolby Atmos are trademarks of Dolby Laboratories. Spatial9 is not affiliated with or endorsed by Dolby Laboratories.
Sources
- Blauert, J. (1997). Spatial Hearing: The Psychophysics of Human Sound Localization, revised edition. MIT Press. Low-frequency, elevation, distance and motion cues.
- Mills, A. W. (1958). On the minimum audible angle. Journal of the Acoustical Society of America, 30(4), 237-246.
- Hebrank, J. and Wright, D. (1974). Spectral cues used in the localization of sound sources on the median plane. Journal of the Acoustical Society of America, 56(6), 1829-1834.
- Bronkhorst, A. W. (2000). The cocktail party phenomenon: a review of research on speech intelligibility in multiple-talker conditions. Acta Acustica united with Acustica, 86, 117-128.
- Litovsky, R. Y., Colburn, H. S., Yost, W. A. and Guzman, S. J. (1999). The precedence effect. Journal of the Acoustical Society of America, 106(4), 1633-1654.
- Barron, M. and Marshall, A. H. (1981). Spatial impression due to early lateral reflections in concert halls. Journal of Sound and Vibration, 77(2), 211-232.
- Neuhoff, J. G. (1998). Perceptual bias for rising tones. Nature, 395, 123-124.
- Bregman, A. S. (1990). Auditory Scene Analysis: The Perceptual Organization of Sound. MIT Press.
